Operating Humidity: <85% RH (non-condensing)
Operating Temperature: 5–45 °C
Measurement Range: 0.2–6.67 (SDI₁₅ min)
Compliance Standard: ASTM D4189-07
Power Supply: 220 VAC ±10%, 50–60 Hz (SDI-6000 Series Fully Automatic Fouling Index Analyzer)
Power Consumption: ≤100 W
Signal Output: RS485 / Dry Contact (Alarm)
Sample Volume: 150 mL
Pre-filter Pressure: 2.07 bar (0.207 MPa)
Filter Holder: Φ25 mm
Sample Water Conditions: 0.3–0.6 MPa, >1 L/min
Input Air Pressure: ≥0.5 MPa
Water Inlet: 6 mm tube
Water Outlet: 6/8 mm tube
Air Inlet: 8 mm tube
Filter Membrane Specification: Width 35 mm, Length 6 m, Pore Size 0.45 μm
Measurements per Roll: ≥150 times/roll
Number of Channels: 1, 2 channels
