Technical Parameters:
Display: Multi-line adjustable backlit LCD
Measurement Range: 0 - 10 mg/L
Analysis Cycle: User-selectable, 110 seconds to 10 minutes
Accuracy:
0 - 6 mg/L: ±5% or ±0.03 mg/L as Cl₂, whichever is greater
6 - 10 mg/L: ±10%
Resolution: 0.01 mg/L
Measurement Method: USEPA-approved DPD colorimetric method for measuring free or total chlorine
Standard Outputs: 4-20 mA and RS-485 Modbus
Alarm Outputs: Two user-configurable relay outputs based on measurement values
Power Supply: 100-240 VAC, 47-63 Hz
Inlet Water Pressure: 0.3 - 10.3 bar (5 - 105 psi)
Enclosure: ABS plastic, IP66 rating
Mounting Dimensions: 12.82" x 12.25" x 5.06"
Shipping Dimensions: 41 cm x 41 cm x 26 cm (16" x 16" x 10")
Net Weight: 2.7 kg (6 lbs)
Shipping Weight: 3.6 kg (8 lbs)
Waste Discharge Flow Rate: 200-400 mL/min
Storage Temperature: -20℃ to 60℃ (-4 °F to 140 °F)
Operating Temperature:
Analyzer Environment: 0 ℃ to 55 ℃ (32 °F to 131 °F)
30-day Reagent Pack Environment: 0 ℃ to 40 ℃ (32 °F to 104 °F). Service life will be less than 30 days if exposed to temperatures exceeding 40℃.
Standards and Certifications: CE, UL, CSA (ETL, ETLc), ABS (American Bureau of Shipping) certified
Ordering Guide:
Free Chlorine Analyzer: LU720-G, 0-10 mg/L, includes one-month supply of pre-packaged reagents
Pre-packaged Reagents: LU720.01, Service Life: One month (with continuous measurement)
